    Machanism Barcode Label Printers 3 Inches Qr Code Printing Price Tag For Clothing

    Ask Lasest Price
    Brand Name : MASUNG
    Model Number : EP802-TU(label version)
    Certification : CE FCC RoHS
    Price : 180-185USD/piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 unit per month
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    Machanism Barcode Label Printers 3 Inches Qr Code Printing Price Tag For Clothing

    High Quality Machanism Barcode Label Printers 3 Inches QR Code Printing Price Tag for Clothing


    Detailed Product Description
    Printing Method:Thermal Dot LinePrinter Head:ROHM
    Printer Cutter:OYANEDots:384 Dots
    Speed:250 Mm/sPaper Thickness:0.06~0.2 Mm
    Paper Loading:Easy Paper LoadingPower Supply:DC24±10% V
    Interfaces:USB/RS232

    Introduction:

    EP802-TU(0A) is a fully integrated Kiosk Printer suitable for all your Kiosk, ATM,Self-service terminals & Parking system printing requirements.

    1.With a high maximum print speed of 250 mm per second,

    2. it has the benefit of fitting in smaller cabinet spaces where it provides an Easy paper roll replacement and rear paper feed with auto load and cut feature.

    3. A clean paper path ensuring reliable ticket presentation and delivery.

    4.Serial and USB Communication options standard in each printer, with a individual power switch for easier and safe maintenance.


    Kiosk Thermal Printer Specifications:


    Control boardEP802_3
    Thermal printer headBrand name: ROHM
    Auto cutterBrand name: OYANE


    Printing
    Printing methodThermal dot line
    Dots640dots
    Speed250mm/s (max)
    Printing width80mm (max)
    Paper width80/82.5 mm
    Paper thickness0.06~0.2 mm
    Paper loadingEasy loading ( horizontal 180°)
    Cutting methodFull/partial
    Print head lifeOver 100KM
    Printing formatinverse,underline,italic,bold
    Cutter life60μm paper1,000,000 cuts
    200μm paper500,000 cuts
    Baud rate9600,19200,38400,115200
    FontASCII9*17,12*24
    Chinese24*24dots
    DetectionTPH temperatureTemperature sensor
    Mechanism open detectionMicro switch
    “anti-drag ticket detection
    Mechanical sensor
    Paper blocked detection
    Paper near end detectionPhoto-interrupter
    Black mark detection
    Paper cutting detection
    Paper presence detection
    ConditionsPower supplyDC24±10% V
    Load current1.5A continuous
    61mA Standby
    3.2 A Peak
    InterfacesRS232,USB
    PaperPaper typeThermal paper roll
    Recommended paper typeKANZAN KF50
    KP460
    MITSUBISHIPG5075
    TL4000
    Environmentoperating temperature-10~60℃(no condensation)
    operating humidity20%~80%RH(40℃,85%RH)
    Storage temperature-20~70℃(no condensation)
    Storage humidity10%~90%RH(50℃,90%RH)
    DimensionDimensionL*W*H=308*119.3*73.2mm
    WeightApprox 1.3kg (without paper roll )

    Features of Kiosk thermal printer:
    Brand: hot head and automatic cutting machine
    Ultra-high printing speed, maximum 250mm /s
    Unique "drag reduction" ticket system
    Smart paper panel with led
    Tight footprint
    Wide range of paper thickness :0.06 ~ 0.2mm
    Application of Kiosk thermal printer:
    Queue management system; Video lottery; Game kiosks, kiosk payment; ATM; Parking system; Ticket agent, coupon machine, etc.;
    Advantages of Kiosk thermal printers:
    Original design compact
    Brand printer head and cutting machine
    Flexible installation method
    Large roll support
    USB/RS232 port
    Ultra-high speed printing speed up to 250mm/s
    Simple paper
    OEM and odm services are available

    High Speed Barcode Label Printers 3 Inches QR Code For Payment Kiosks System
