56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module

    Buy cheap 56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module from wholesalers

    Buy cheap 56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module from wholesalers
    • Buy cheap 56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module from wholesalers
    • Buy cheap 56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module from wholesalers
    • Buy cheap 56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module from wholesalers
    • Buy cheap 56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module from wholesalers

    56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module

    Ask Lasest Price
    Brand Name : MASUNG
    Model Number : MS-LP212A
    Certification : CE/ROHS
    Price : negotiable
    Supply Ability : 2000 set per month
    • Product Details
    • Company Profile

    56mm RS232 Barcode Dot Line Thermal Printing Label Printer Module

    New Product Best 56mm RS232 Barcode Dot Line Thermal Printing


    MS-LP212 is an 2 inch embedded thermal label printer equipped with an auto-peel off mechanism and a roll re-winder.


    Features :

    High speed printing

    Automatically label peeing off mechanism

    Super paper roll re-winder

    Auto paper calibration system

    Wide range 35~60 mm paper width

    Accurate buzzer and indicators alarming


    specification:

    ModelMS-LP212A

    print

    Printing methodDot line thermal printing

    Total dots per

    line

    448 dots
    Printing width56mm(max)
    DetectionThermal head temperatureThermal sensors
    Platen openMechanical switch
    Paper gapReflective infrared light sensor
    Cover openMechanical photoelectric sensor
    Out of Paper detectionReflective infrared light sensor
    PowerWorking voltage24±10%V/2A
    Power standbyAbout 17mA
    PaperPaper width35~60mm
    Paper roll inner core≥25mm
    Paper roll outer diameter120mm(max)
    environmentOperation temperature-10~50°C(no condensation)
    Operation humidity20~85%RH(40℃/85%RH)
    Storage temperature-20~70°C(no condensation)
    Storage humidity10~90%RH(50℃/90%RH)
    Service life

    Activation pulse

    resistance

    100,000000
    Abrasion resistance100KM
    DimensionW112mm*D217.46mm*H106.43mm(width*depth*height)
    MassAbout 1.65kg
    Communication interfaceRS232 & USB

    Application:

    weighing scale; monitor system; measurement device, barcode printers and so on.
