    Roll To Roll Kiosk Label Printer Retract Presenter For Casino Gaming Machine

    Ask Lasest Price
    Brand Name : MASUNG
    Model Number : W80A
    Certification : CE/ROHS/CCC/FCC
    Price : USD240~255/set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5,000 units/monthly
    • Product Details
    • Company Profile

    Roll To Roll Kiosk Label Printer Retract Presenter For Casino Gaming Machine

    W80A

    Most cheapest 80mm Kiosk Printer with Retract Presenter for Casino Gaming Machine and LED Display


    Features:

    Brand name thermal head & auto cutter

    Ultra Highly printing speed Max 250 mm/s

    Ticket retracting capability

    Multiple paper loading direction

    Wide range paper thickness: from 0.06 ~ 0.2 mm


    Specification:

    ModuleW80A
    Control boardEP802_3
    Thermal printer headBrand name: ROHM
    Auto cutterBrand name: OYANE

    Printing


    Printing methodThermal dot line
    Dots640dots
    Speed250mm/s (max)
    Printing width80mm (max)
    Paper width60/80/82.5 mm
    Paper thickness0.06~0.2 mm
    Paper loadingEasy loading ( horizontal 180°)
    Cutting methodFull
    Print head life100KM
    Printing formatinverse,underline,italic,bold

    Cutter life


    60μm paper1,000,000 cuts
    200μm paper500,000 cuts
    Baud rate9600,19200,38400,115200
    FontASCII9*17,12*24
    Chinese24*24dots
    DetectionTPH temperatureTemperature sensor
    Mechanism open detectionMicro switch
    Paper presence detectionMechanical sensor
    Ticket out detection
    Paper near end detectionPhoto-interrupter
    Black mark detection
    Paper cutting detection
    Paper retracting detection
    ConditionsPower supplyDC24±10% V
    Load current

    1.5A continuous

    61mA Standby

    3.2 A Peak

    InterfacesRS232,USB
    PaperPaper typeThermal paper roll
    Recommended paper type

    KANZAN KF50

    KP460

    MITSUBISHIPG5075

    TL4000

    Environmentoperating temperature-10~60℃(no condensation)
    operating humidity20%~80%RH(40℃,85%RH)
    Storage temperature-20~70℃(no condensation)
    Storage humidity10%~90%RH(50℃,90%RH)
    DimensionPaper holder 45° upward ( 150mm paper roll)L*W*H=328*122.3*163 mm
    Paper holder horizontal (150 mm paper roll)L*W*H=355*122.3*288 mm
    Paper roll vertical (150 mm paper roll)L*W*H=196*122.3*288 mm
    WeightApprox 1.49kg(without paper roll )

    Application:

    Sports betting terminal; video lottery machine; gaming kiosk, payment kiosks; ATM; parking system; ticket vendor, airport boarding check printer, ATB tags printer and more
