    direct thermal machine USB thermal Barcode Label Printers for payment kiosk

    Ask Lasest Price
    Brand Name : MASUNG
    Model Number : MS-D347-TL
    Certification : CE/ROHS
    Payment Terms : T/T
    Price : USD 120~150/set
    Supply Ability : 5000 set per month
    • Product Details
    • Company Profile

    direct thermal machine USB thermal Barcode Label Printers for payment kiosk

    Direct thermal machine USB thermal receipt printer Barcode Label Printers for payment kiosk


    Features:

    • OEM offer
    • certificated productsPrompt delivery
    • Brand name printer mechanism
    • High printing speed
    • Auto cutting (full/partial by Adjustable)
    • Interfaces diversification
    • Multiple detection sensors
    • Paper jam prevention
    • Support Windows/Linux/Android OS

    Specification:


    mechanism:

    CAPD347

    Printing method

    Thermal dot line printing

    Dots/line

    576 dots/line

    Dot pitch

    8 dot/mm

    Paper width

    80 mm

    Printing width

    72 mm

    Paper thickness

    54~78 um

    Printing speed

    200 mm/s

    Paper feed direction

    180° horizontal

    Sensors

    Head temperature

    Thermistor

    Paper press shaft

    Mechanical switch

    Paper end

    Photo interrupter

    Paper loading

    Easy loading

    Font size

    ASCII:9*17;12*24;

    Chinese: 24*24

    Power supply

    Logic circuit

    4.75~5.25 V

    Motor

    21.6~26.4 V

    Dimension (L*W*H)

    186.9*121.5*112.2 mm

    Weight

    Approx 1.92 kg

    Reliability

    Circuit: over 1,000,000,000 pulses

    Cutter: over 7,000,000 cuts

    Thermal head: over 100 km

    MCBF: 37,000,000 lines

    Ambient environment

    Work temperature

    -10 ℃~50℃

    Work humidity

    20~85% RH

    Storage temperature

    -25℃~70℃

    Storage temperature

    10~90% RH


    Interface

    RS-232 /USB/Parallel

    power supply

    DC 24V/2.5A

    Command set

    ESC/POS

    Barcode

    supported

    Firmware location

    512KB Flash memory

    Buffer

    32 KB

    SRAM

    64KB (extra)

    Driver

    Parallel/USB driver

    System

    Windows/Linux/Android OS

    Accessories:

    Sensors

    paper near end sensor;

    paper jam sensor;

    dragging paper sensor;

    Paper roll holder

    Paper bezel ( paper guide)

    Interface connector

    Power supply unit

    Cable


    Application:


    Self-service terminal payment kiosk; information machine; parking system; queue management kiosk; ATM; gas station kiosk; ticket vendor, multimedia kiosk; and moredirect thermal machine USB thermal Barcode Label Printers for payment kiosk
