    58mm Thermal Panel Mount Printer For Weighing Scales , High Speed 70 mm/s

    Ask Lasest Price
    Brand Name : MASUNG
    Certification : CE; ROSH
    Model Number : MS-601(a)
    Delivery Time : 5~8 days
    Payment Terms : T/T/Paypal/Western union
    Supply Ability : 3,000 units/monthly
    • Product Details
    • Company Profile

    58mm Thermal Panel Mount Printer For Weighing Scales , High Speed 70 mm/s



    58mm Thermal Panel Mount Printer For Weighing Scales , High Speed 70 mm/s




    Quick details:


    ► Easy paper loading
    ► Panel LED indication
    ► High speed 70 mm/s
    ► Built-in control board
    ► Bucket for big diameter paper roll
    ► Low power supply
    ► Low noise


    Description:


    MS-601(a) is one type easy paper loading 58mm thermal panel mount printer. RS-232/TTL ports are available.



    Specifications:

    Mechanism


    Printing method

    Thermal dot line printing

    Dots number

    384 dots/line

    Printing density

    8 dots/line

    Printing speed

    Max 70 mm/s

    Printing width

    40 mm

    Paper width

    42.5±0.5 mm

    Roll diameter

    Max 46 mm

    Working voltage

    DC 4.2~8.5 V

    Head sensor

    thermistor

    Paper sensor

    Photo interrupter

    Reliability

    Mechanism life: over 50 km;
    Pulse numbers: 10,000,000,000 times

    Working environment

    Temperature:0~50℃
    Humidity: 20~85% RH

    Control board


    Interface

    TTL/RS-232/USB

    Command set

    ESC/POS

    Firmware location

    Flash memory

    Buffer

    4 K bytes

    Supporting devices

    Paper end sensor, paper near end sensor

    Total weight

    Approx 63 g

    Panel dimension

    88(L)*76(W)*42(H)


    Accessories

    cable



    Application:


    Panel printer, medical printer, self-service terminal, vehicle-mounted recorder, meters and measurement device,gas pumps and more



    Competitive Advantage:



    Green product
    Brand-name printer parts
    Customization offer
    Prompt delivery
    Small order accepted
    Buyer label offer
