    Ticket Embedded 3 Inch Thermal Printer Portable 80mm Support Many Languages

    Ask Lasest Price
    Brand Name : MASUNG
    Model Number : MS-530I(b)
    Certification : CE; ROSH
    Payment Terms : T/T/Paypal/Western union
    Supply Ability : 3,000 units/monthly
    Delivery Time : 5~8 days
    • Product Details
    • Company Profile

    Ticket Embedded 3 Inch Thermal Printer Portable 80mm Support Many Languages

    Ticket Embedded Thermal Printer Module 80mm Support Many Languages


    Quick details:


    EPSON M-T532 printer mechanism

    Fast speed: 150mm/s

    Compact panel structure

    Controlling board built in mechanism

    Horizontal(180°) paper feeding

    Auto cutter: full/partial by option

    Android APK and APP avaiable

    ►Ticket embedded printer

    ►Support many languages


    Description:


    MS-530I(b) is panel mount 3 inch thermal printer which take uses of epson printer head for barcode label printing.


    Specification:


    Mechanism

    M-T532

    Printing method

    thermal dot line printing

    Dot structure

    640 dots/line

    Paper width

    80mm

    Printing speed

    150mm/s

    Paper loading

    easy paper loading

    Power supply

    printer head 24v/1.9A

    Auto cutter 24v/1.4A

    Reliability

    mechanism: more than 150km

    Auto cutter: 1,000,000 cuts

    Sensor

    TPH temperature: thermistor

    Paper near end/black mark: photo interrupter

    Controlling board

    Interfaces

    USB/RS-232

    Power supply

    DC 24v/2.5A

    Working temperature


    0~55 ℃

    ARM

    32 bits

    Flash memory

    32~128 k bytes

    SRAM

    6~20 k bytes

    Font

    12*24/9*17/16*16/24*24

    Supporting devices

    automatic cutter, paper sensor, head-up sensor, LF switch, error LED, paper end LED

    Concise driver

    Winows/Android/ Linux

    Physical property


    Dimension

    126.76*91.9*56.4 mm

    weight

    517.2 g


    Application:


    Self-service terminal; coupon machine; bank call distributor; parking system; payment kiosk; ticket vendor; ATM; queuing kiosk and more


    Competitive Advantage:

    • Certificated product
    • Brand-name printer parts
    • Customization offer
    • Prompt delivery
    • Small order accepted
    • Product performance
    • OEM offer
